Commander X16 Developer Edition Pre-Order

From: $349.99

This item will be released February 29, 2024.

The Commander X16 Developer Edition is now available for Pre-Order!  Payment information will be requested at checkout, however you will not be charged until we start shipping pre-orders.

The release date is an estimate and is subject to change. If this date changes you will be notified via email, please make sure that texelec.com is on your safe list so we don’t end up in your spam/junk mail.

You can pre-order one or more Commander X16 Developer Edition machines as well as select additional items to be shipped with your Pre-Order below:

SKU: TECX16PREORDR Category:
Product Quantity

Commander X16 Developer Edition

The 8-Bit Guy’s dream computer!
Learn More...

X

Commander X16 Developer Edition

If you already know about the Commander X16, and have been waiting for the release, then read no further!  If this system is new to you, or if you’re interested in the specifications, please feel free to read on.

System specifications:

  • Western Design 65C02 CPU running at 2, 4 or 8MHz selectable via jumper on-board
  • Western Design 65C22 VIA for IEC Serial, I2C and SNES Controller Ports
  • Open Socket for 65C22 USER PORT IC with 26 pin/db-25 header
  • 39.75KB of “LOW RAM” exposed to BASIC and static for use in other languages
  • 512KB of “HIGH RAM” available in 8KB selectable banks (Upgradeable to 2MB)
  • 512KB to 4MB of ROM – 512KB available in 16KB banks on the motherboard – 3.5MB available space on the expansion slot
  • VERA standalone video module supporting up to 4096 colors, many modes and SDHC card storage
  • VERA 16-Channel Programmable Sound Generation – Pulse, Sawtooth, Triangle and Noise
  • Yamaha YM2151 or YM2164 4 Operator 8-Channel FM Synthesizer IC
  • 4 60-pin expansion slots with I2C, audio inputs to mixer and full access to the CPU bus and ROM
  • The first expansion slot is right angled for cartridge use, but could be replaced with a vertical slot
  • 5 32-byte IO spaces are available on the expansion slot 2 Fast 8MHz and 3 Slow 2MHz lines
  • I2C & Audio Expansion header
  • Microchip MCP7940N I2C Realtime Clock with RAM with battery for Profile storage
  • PS/2 Mouse and Keyboard ports
  • Standard 20 or 24 pin ATX power supply connector support
  • Updates for the VERA, System ROM and System Microcontroller can be installed on-system via software

What’s Included?

  • Fully built and tested Commander X16 Motherboard with VERA Module Installed
  • SDHC card included with demos, games and music application included

Notes:
The Commander X16 Developer Edition was designed to fit in a low-profile Micro ATX computer case.  It will fit in most any ATX case too, so you can use an old machine you have sitting around to house your Commander if desired.  Likewise, nearly any 20 or 24 pin ATX-style power supply will work with the system.  Please ensure your power supply provides +5VDC, +12VDC and -12VDC.  Some modern supplies for PCIe only systems do not provide -12V and it is required for the X16.  We recommend using the lowest wattage ATX supply you have access to.  The system only consumes 3 to 5 watts.

$349.99 each

Commander X16 Developer Edition Upgrade

This option includes 1.5MB of RAM, the User Port IC and the Protection IC.
Learn More...

X

Commander X16 Developer Edition Upgrade

The default configuration of the Commander X16 Developer Edition has 512KB of High RAM. Most applications and games will work within 512KB, but there are some cases where more RAM may be desirable. Future system releases may have only 512KB of RAM, but the Developer Edition is upgradeable to allow for more complex environments used by developers and power users. Likewise, the USER VIA IC (65C22) will allow the use of the User Port. As an added protection measure, two electrostatic discharge protection devices are included to protect the pins of the user-port. The board already has sockets for these chips, so simply turn off the power and pop them in! No soldering required.

This upgrade includes the following:

1 x Western Design Center W65C22S6TPG-14: U28 - 65C22 User VIA IC
2 x Littelfuse SP720APP: TVS1 & TVS2 - ESD Protection Diode Packages
3 x Alliance AS6C4008: U4-U6 - 3 x 512KB SRAM ICs 1.5MB High RAM Upgrade

Commander X16 Mini Perixx Keyboard

The Official Commander X16 Keyboard custom manufactured by Perixx!
Learn More...

X

Commander X16 Mini Perixx Keyboard

This Mini PS/2 wired keyboard has been custom designed by us and produced by Perixx for use with the Commander X16 or a normal PC.  The keyboard contains the custom key graphics used by the Commander X16, including the ‘PETSCII’ graphics characters.  Users familiar with Commodore machines will feel right at home with this keyboard.  While it was primarily meant for use on the Commander X16 Computer, it is a normal PS/2 keyboard with USB support.  Simply obtain a PS/2 to USB adapter and you may use it on a modern PC with the Commander X16 emulators!

Membrane Style Keyboard - 84 keys - 3.2mm of key travel – 5.9 ft Cable
Same specifications as the Perixx PERIBOARD-409PW

Perixx White Optical PS/2 Mouse

This is a white Perixx non-branded PS/2 Optical Mouse to match your Commander X16 keyboard!
Learn More...

X

Perixx White Optical PS/2 Mouse

  • PS/2 Serial Port Mouse - Three buttons with scroll wheel
  • Ergonomic Design 1000 DPI
  • PERIMICE-209P is compatible with the Commander X16 and any PC with a Standard PS/2 Port
  • Product Dimension: 4.3 x 2.3 x 1.5 inches
  • Cable: 1.5 meter / 6 foot

Pico ATX Power Supply

12VDC 160W Pico ATX Power Supply Module
Learn More...

X

Pico ATX Power Supply

The Commander X16 Developer Edition was designed to fit in a standard low-profile MicroATX case.  However, it fits in standard full-height ATX cases and will work with most standard ATX power supplies as well.  If you already have a case, but still need a power supply, this module will work great for the Developer Edition.  You will need a standard 12V AC adapter with a 5.5mm outer / 2.5mm inner diameter barrel jack connector.  We recommend a 3amp supply which is more than enough power for the system and peripherals you may use.Specifications:
24 pin ATX connector, plugs directly into the ATX connector
Input Voltage Range：11.4VDC—12.6VDC
Incoming Current Range：16.0A Max @11.4VDC
Input Surging Current：12.0Amax@12VDC
Work Efficiency: ≥85%
Working temperature/humidity:  -5℃to 55℃/ 45%-75%
CE, ROHS Certification

*Note, if you use your own power supply, please ensure it provides +5V, +12V and -12V.  Some modern supplies for PCIe only systems do not provide -12V and it is required for the X16.  Both 20 and 24 pin ATX power supplies will work correctly with the system.  We recommend using the lowest wattage ATX supply you have access to.  The system only consumes 3 to 5 watts.

Universal AC Power Adapter

Universal AC Power Adapter 12V 3A 36W for EU, UK, US, AU and CN
Learn More...

X

Universal AC Power Adapter

This supply will work with the Pico ATX power supply module we offer for the Commander X16 Developer Edition. It outputs 12VDC @ 3Amps, which is an ideal size for the system. This universal AC adaptor accepts a wide range of voltages and frequencies which allows it to work with most power systems around the world. It also includes four interchangeable AC plug types for easy connection.

Specifications:
Input voltage: 90-264VAC / 47-67Hz
Output voltage: 12VDC
Output current: 3Amps
Output power: 36W
Efficiency: 90%
Barrell Jack: 5.5mm / 2.5mm
AC Plug types: USA / Japan, Australia, Europe and United Kingdom
Cable Length: 1.2 meter / 47 inches

Commander X16 Expansion Port Prototype Card

Expansion Port Prototype Card for the Commander X16 Developer Edition.
Learn More...

X

Commander X16 Expansion Port Prototype Card

This 60-pin prototype PCB is designed for low profile or standard height ATX cases. It uses a standard right angle DB25 connector and one of two standard PCIe brackets. The exposed DB25 connector may be used for your prototype or connected to the internal User Port header. Great for DIY projects!

Note: The LAZER3D case was designed to be as low profile as possible and does not accomodate vertical expansion boards in most cases. You may be able to install them in the machine if they don't have ports which protrude enough to hit the back of the case. However, the lid will not fit on the system with them installed.

Description

Thank you for supporting the Commander X16 project!

Standard purchases cannot be made along side your pre-order.  If you wish to order items not related to the Commander pre-order you will need to place a separate order.  If you add standard items to your cart while your pre-order is awaiting checkout, your cart will be emptied.

Only one Pre-Order is allowed in the cart at a time so be sure to make all your selections and quantities here before adding to cart.

Additional information

Weight 17 oz
Dimensions 15 × 15 × 5 in

Commander X16 Developer Edition

Weight 27 oz

Commander X16 Developer Edition Upgrade

Weight 2 oz

Commander X16 Mini Perixx Keyboard

Weight 17 oz

Perixx White Optical PS/2 Mouse

Weight 4.3 oz

Pico ATX Power Supply

Weight 2.5 oz

Universal AC Power Adapter

Weight 12 oz

Commander X16 Expansion Port Prototype Card

Weight 2.3 oz
Options

PCB Only, PCB + Low Profile Kit, PCB + High Profile Kit
